Name: Factory Supply Rugged Corded 1D 2D Imager Barcode Scanner With High Performance Barcod Scanner Handheld
Brand: Guangzhou TiCODE Electronics Technology LTD.
SKU: RiCODE TI6200HP
Availability: InStock

Home Products 2D Wired Barcode Scanner

Factory Supply Rugged Corded 1D 2D Imager Barcode Scanner With High Performance Barcod Scanner Handheld

Product Details:

Place of Origin:	Guangzhou, Guangdong China
Brand Name:	RiCODE
Model Number:	RiCODE TI6200HP

Contact Now

Detailed Product Description

Private Mold:	Yes	Products Status:	Stock
Type:	Barcode Scanner	Scan Element Type:	2D
Colour Depth:	32 Bit	Interface Type:	Usb, COM, RS232
Max Paper Size:	A4	Optical Resolution:	≥ 3 Mil
Scan Speed:	200	Warranty(year):	1-Year
After-sales Service:	Repair, Free Spare Parts, Call Center And On-line Technical Support	Software Development Kit (sdk):	Yes
Color:	Yellow	Application:	Industry
Product Name:	2D Wired Barcode Scanner	Interface:	USB, USB-COM, RS232
Light Source:	2D Imager	Color:	Yellow+Black
Scan Mode:	Manual Trigger, Auto-detective	Resolution:	3 Mil
Decode Capabilities:	1D + 2D + QR Code	Material:	Dual-color ABS/PC+TPU; Single-color ABS+PC; Transparent: PC;

Applications

* Automobile industry, Heavy Machinery, Electronics industry;

* Large warehouses, sea port and cargo terminals;

* Large logistics enterprises;

* Other place require higher scanning performance or higher scanning intensity.

Product Paramenters

Model	TI6200HP
Input Voltage	5V DC, ±0.25V
DC Current	360mA(working); 72mA(standby)
Scan Module	2D Imager
Lighting Source	White LED
Aiming line	Red LED
Resolution	≥ 3 mil
Angle Tolerance	Skew ±72°, Pitch ±72°, Roll 360°
Trigger Mode	Manual trigger, Auto-detective
Cable Length	2 meters
2D Code types	QR Code, Data Matrix, PDF417, HANXIN, MicroQR, Aztec etc.
1D Code types	UPC-A, UPC-E,EAN-8, EAN-13, EAN-ISBN/ISSN, Code 39, Code 39(Full ASCII), Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of 5,Codabar, Code 128, Code 93, Code 11 MSI/Plessey, UK/Plessey, UCC/EAN 128, China Post Code, GS1 Data Bar (formerly RSS) etc.
Interfaces	USB, RS232, USB-COM
Shock proof	withstand multiple drops from 2.0 m to concrete surface
Dust & Water proof	IP54

Features

1. Outstanding scanning sensitivity and decoding ability;
2. good at reading worn code, DPM, high reflecting, high density, small size etc.;
3. IP54 proof level, competent for harsh environment;
4. Good ergonomic design for long working time;
5. Capable for monitor-displayed code;
6. Auto-sensing(Optional stand)

Product Description

Company profile

Packing & Shipping

FAQ

1. Why choose us?
* Passionate, experienced and highly-educated R & D and sales team;
* Reasonable price and reliable products, skillful and careful assembly;
* Strict quality assurance and quick aftersales service;
* Lifetime technical support, can come with customized setting.

2. Are OEM and ODM available?
* Yes, they are. As a professional manufacturer, we offer OEM and ODM service.

3. How about your product warranty?
* We offer one-year warranty upon delivery.

4. How about the aftersales support?
* We will offer on-time response for online enquiries from oversea users. Please feel free contact us by email, Ali-Trade, WhatsApp, WeChat and SKYPE.

5. Payment method?
* Now T/T and PayPal are available, more is coming.
